Telit LE910C4-WWX ThreadX Series LTE Cat 1/4

SKU LYN-200-00105
Availability:
100 in stock, ready to ship
Original price $48.02 - Original price $48.02
Original price
$48.02
$48.02 - $48.02
Current price $48.02

Special Offer!

5% discount in the basket for your orders of 10 or more pieces

The LE910C1 and LE910C4 4G LTE modules are compliant with the 3GPP Release 10 and are available with optional quad-constellation GNSS capability.

  • Best-in class 3GPP rel10 platform
  • MTC features ready according to 3GPP Rel.12
  • Easy to integrate with peripherals and actuators using USB 2.0 HS, UART and user definable GPIOs
  • Internet friendly with integrated TCP/IP and UDP/IP stacks
  • Simple drop-in migration and technology design reuse path to 2G and 3G with any xE910 module
  • LTE FDD Cat.4, 3GPP release 10 compliant
  • LTE FDD Cat.1, 3GPP release 10 compliant
  • Rx Diversity and MIMO DL 2×2
  • Single Rx option
  • VoLTE support
  • SMS over IMS
  • Built in UDP/TCP/FTP/SMTP stack
  • IPv4/IPv6 stack
  • Control via AT commands according to 3GPP
  • TS 27.005, 27.007 and Telit Custom AT commands
  • SIM application Tool Kit 3GPP TS 51.014
  • OMA-DM Telit Software Management
  • Simultaneous support of GPS, Glonass, Beidou, Galileo, QZS

Hardware & Electrical Specification

  • Dimensions: 28.2 x 28.2 x 2.2mm
  • Dimensions LE910C1-WWX and LE910C4-WWX: 29.4 x 29.4 x 2.2 mm
  • Extended temperature range: -40 °C to +85 °C
  • LGA form factor
  • Supply voltage range:

    • Nominal: 3.8 VDC
    • Range: 3.4 – 4.2 VDC
